C3868A - HP Natural Tracing Paper - 914 mm x 45.7 m – Wide Format Media

C3868A - HP Natural Tracing Paper - 914 mm x 45.7 m

Produce clear reproducible final drawings
C3868A - HP Natural Tracing Paper - 914 mm x 45.7 m

C3868A - HP Natural Tracing Paper - 914 mm x 45.7 m

Produce clear reproducible final drawings
SKU : C3868A
Inventory : 8
Unit price  per
Shipping calculated at checkout.
- +
Login to view price

Product Description

Communicate with clarity
Clear, concise drawings can avoid costly mistakes. Achieve crisp black and color line
quality—HP Natural Tracing Paper provides excellent bleed control—for archivable prints.

Deliver easy-to-read plans
Your technical drawings need to communicate without ambiguity. Produce easy-to-understand, easy-to-read reproducible prints with HP Natural Tracing Paper, designed together with Original HP inks.

Deliver on time, on budget
Get the results you expect with the first print. HP printing materials are designed together with Original HP inks and your DesignJet printer to provide consistent, quality results.

Target customers Applications Benefits

Architects

Engineering (CAD), architecture (AEC), and Geographic Information
Systems (GIS) archives or reproductions

Crisp black and color line quality

Engineers

Excellent bleed control

Geographic Information Systems (GIS)

Archivable prints

Technical Specifications

Weight

90 g/m² per ISO 536 Test Method

Thickness

76 microns/3 mil per ISO 534 Test Method

Opacity

25% per TAPPI T-425 Test Method

Brightness

61% per TAPPI T-452 Test Method

Whiteness

Greater than 120 per ISO 11476 Test Method

Finish

Matte

Operating temperature

15 to 35° C / 59 to 95° F

Operating humidity

20 to 80% RH

Dry time

Dry time Less than 2 minutes (at 23°C, 50% RH)

Lamination

Yes

Shelf life

1 year, unopened in original packaging

Storage temperature

0 to 40° C / 32 to 104° F

Storage humidity

5 to 95% RH

Country of origin

Product of United Kingdom

Imperial Metric
Width 36 in 914 mm
Length 150 ft 45.7 m
Config 1 Roll 1 Roll
Printer DesignJet T2300
Printer DesignJet T2500/T2530
Printer DesignJet T7100
Printer DesignJet T520
Printer DesignJet T790
Printer DesignJet T1120
Printer DesignJet T610
Printer DesignJet T795
Printer DesignJet T1200
Printer DesignJet T920
Printer DesignJet T3500
Printer DesignJet T7200
Printer DesignJet T770
Printer DesignJet T1100
Printer DesignJet T1300
Printer DesignJet T1500/T1530
Product Group HP Natural Tracing Paper
Printer DesignJet T730
Printer DesignJet T830
Printer DesignJet T930
Printer DesignJet Z2100
Printer DesignJet Z3100
Printer DesignJet Z3200
Printer DesignJet Z5200
Printer DesignJet Z6100
Printer DesignJet Z6200
Printer DesignJet Z6600
Weight (gsm) 90
Thickness (micron) 76
Thickness (mil) 3
Printer DesignJet Z3200PS
Printer DesignJet Z3100PS
Printer DesignJet Z6800
Printer DesignJet Z6810
Printer DesignJet Z6610
Printer DesignJet 111
Printer DesignJet T620
Printer DesignJet T930
Printer DesignJet T1700
Printer DesignJet T120
Printer DesignJet T7100 Monochrome
Printer DesignJet 4500
Printer DesignJet 4520
Printer DesignJet 4000
Printer DesignJet 4020
Printer DesignJet 1050C
Printer DesignJet 1055CM
Printer DesignJet 1050C Plus
Printer DesignJet 1055CM Plus
Printer DesignJet 500
Printer DesignJet 500 Monochrome
Printer DesignJet Z2600
Printer DesignJet Z9
Printer DesignJet XL 3600
Printer DesignJet T100
Printer DesignJet T125
Printer DesignJet T130
Printer DesignJet T525
Printer DesignJet T530
Printer DesignJet T1600
Ink Compatibility Aqueous
Regional Availability AMS
Regional Availability EMEA
Regional Availability APAC
